Swivel machine vise 136 mm
jaws136 mmopening160weight13 kg
3 720 ₴incl. VAT
3 100 ₴ excl. VAT · invoice for companies and sole proprietorsGet an invoice or a quote
Nova Poshta, Meestat the carrier's rate
Freight carrierat the carrier's rate
Pickup, Dniprofree
Warranty12 months
Specifications
| Main | |
|---|---|
| Country of origin | Taiwan |
| Length | 387 mm |
| Width | 166 mm |
| Height | 114 mm |
| Weight | 13 kg |
| Vise type | machine |
| Swivel mechanism | Yes |
| Jaw width | 136 mm |
| Jaw height | 36 mm |
| Max. vise opening | 160 |
| User specifications | |
| article number | 7200-0210 |
| rotation angle | 360° |
Description
This 136 mm swivel machine vise with manual drive holds the workpiece during milling, drilling and other machining operations. The swivel base turns the part through 360 degrees without re-clamping, which saves set-up time on repeated jobs. The body parts are cast iron, accuracy class H to GOST 16518 (DIN 6370).
Jaw width 136 mm, jaw height 36 mm, maximum opening 160 mm. A thrust bearing reduces the force needed on the handle, and disc springs keep the workpiece clamped securely. The vise is located on the machine table by keys and fixed with two bolts. It suits work on milling and drilling machines in production.
Manually operated machine vises are designed for holding workpieces during machining on metal-cutting machines. Vise accuracy class N according to GOST 16518 (DIN 6370). A swivel vise consists of a parallel non-swivel vise and a swivel table.
The main body parts of the vise are made of cast iron.
The vise is located on the machine table with keys and fastened with 2 bolts.
The thrust bearing reduces the handle effort when clamping a workpiece. Disc springs make workpiece clamping more reliable.
