FDB Maschinen MLQ300TB combination woodworking machine

The FDB Maschinen MLQ300TB combination woodworking machine is designed for sawing wood and wood-based panels (plywood, hardboard, chipboard), as well as various operations on wooden workpieces:

• Jointing;
• Planing to thickness (thicknessing);
• Mortising (drilling);
• Milling.

The machine also comes with grinding wheels for circular saw blades and planer knives plus a fixture for holding them, which significantly extends its capabilities.

FDB Maschinen MLQ300TB combination woodworking machine features:

• Rigid reinforced cast-iron frame;
• Improved cross-cut carriage;
• A powerful motor driving through two V-belts ensures high reliability and durability;
• The machine can sharpen jointer knives, circular saw blades and cutters;
• Simple and reliable operation.

Specifications:

Model	MLQ300TB
Rated power (220 V, 50 Hz), W	2200
Spindle speed, rpm	3100
Max. jointing (planing) width, mm	300
Max. planing depth, mm	3
Max. workpiece thickness when thicknessing, mm	110
Min. workpiece thickness when thicknessing, mm	10
Max. cutting depth, mm	100
Saw blade size, mm	250×2,6×25
Jointer cutterblock diameter, mm	70
Number of jointer cutterblock knives, pcs	3
Planer knife size, mm	TBC
Thicknesser feed rate, m/min	6,5
Max. cutter diameter, mm	85
Max. cutter width (height), mm	70
Max. lifting table travel, mm	40
Mortiser longitudinal travel, mm	120
Mortiser cross travel, mm	100
Max. mortiser vertical travel, mm	50
Additional sliding table travel, mm	960
Height from floor to jointer table surface, mm	700
Jointer table size (L×W), mm	1210×390
Thicknesser table size (L×W), mm	560×300
Saw lifting table size (L×W), mm	700×170
Additional sliding table size (L×W), mm	435x345
Dust collector port diameter, mm	--
Overall dimensions (L×W×H), mm	1210×1575×850
Net weight, kg	200
